Laser

:

Nd: YAG

Wave Length

:

1064nm

Cone Angle

:

16°

Mode of Operation

:

Q - Switched

Energy Delivery

:

Burst Mode

Energy

:

0.5 to 10mJ - Variable

Spot Size

:

10 Microns

Mode

:

Fundamental

Cooling

:

Air Convection

Aiming Beam

:

Dual Laser Diode 650nm

Focus Shift

:

±150μm (Posterior Offset)

Operation

:

Micro Processor Controlled

Pulse Duration

:

<4 ns

Pulse Repetition Frequency

:

Max. 2 Hz

Magnification

:

3 Step (10,16,25) [ 5 step - optional]

Working Distance

:

100mmm

Eye Piece

:

12.5X, Diopter Adjustable - 6D to +6D

Inter Pupillary Distance

:

52mm to 75mm

Illumination

:

12V, 30W Pre - Focused Halogen Lamp

Slit Width

:

Continuously Variable (0 to 14mm)

Slit Length

:

14, 10, 8, 5, 3, 2, 1 mm

Slit Rotation

:

0° to 180°

Filters

:

Cobalt Blue and Red Free Green

Power Supply

:

230V, 50Hz, 5A. (110V Optional)

Dimensions

:

86cm x 52cm x 51cm

Net Weight

:

37 kg. (Approx.)
