DIATHERMY

10 Watts High precision power output
Variable power setting from 05-100% at a step of 5%
Output Short circuit protection ; Power Linear / Non Linear option
Bipolar Micro forceps and pencil eraser supported

IRRIGATION / ASPIRATION

Regulated by the height of the irrigation source
High Precision Pedal controlled Linear Venturi Aspiration
Real time Vacuum achieved by Hi-caliber sensor based Software
Vacuum level range from 05-500 mmHg at a step of 05 mmHg
Preset value : programmable and recall facility

REFLUX

Pulsed / Continuous Reflux

VITRECTOMY

Pneumatically powered by external Air Compressor or Gas Cylinder
Cutter speed selection from 60-900 cuts per minute

PHACO
EMULSIFICATION

Ultrasonic power generation at 40 Khz
Continuous Mode, Pulse Mode ( 01-15 pulse/sec selection ),
Ocupulse , Burst Mode and Micro Pulse mode
Phaco power from 0- 100% ; Linear / Non-Linear option
High speed processor based and continuously auto tuned
UST : Ultrasonic usage time ; EUT : Effective usage time display
Preset value : Programmable and recall facility
Voice prompt system ( enable / disable option )

FOOT SWITCH

Easy maneuverable
Vitrectomy RDY/OFF control through foot switch

DISPLAY

240 x 64 Graphical Display with Preset & Actual ( real time ) display
Vitrectomy on/off indication

CONTROL PANEL

Simple layout & Feather touch switches for various settings

DIMENSIONS

30cm W x 27cm D x 10.0cm H

ELECTRICAL

230 VAC , 50-60Hz, Single phase

WEIGHT

7.8 Kgs (approx)

ACCESSORIES

Ultrasonic Hand-piece, Phaco Tip, Sleeves, Test chamber, Tubing set,
Bi-manual Probe , Vitrectomy Cutter, Diathermy Forceps,
Autoclavable silicon cord.
